Fiber Laser Cutting Machine 3000W, Working Area: 5 x 10 feet or 5 x 20 feet
Price
You save: $4,000.00! (10.28%)
Fiber Laser Cutting Machine 3000W, Working Area: 5 x 10 feet or 5 x 20 feet
Product Description
INDUSTRIAL FIBER LASER METAL CUTTING MACHINE
5 × 10 FT Working Area | Up to 3000W Laser Power
Larger 5 × 20 FT Model Available – $48,000
PRICE INCLUDES IMPORT DUTIES AND SHIPPING TO YOUR DOOR!
We offer high-performance fiber laser metal cutting machines designed for precision, efficiency, and reliability.
Our machines are suitable for sheet metal fabrication, industrial manufacturing, metalworking shops, and custom metal cutting applications.
DELIVERY, INSTALLATION & SUPPORT
- All-Inclusive Delivery: Price includes machine cost, import duties and shipping directly to your address.
- Easy Unloading: You only need to arrange a forklift to unload the machine upon delivery.
- Machine Testing: We can set up, test, and demonstrate machine operation before shipment in factory.
- Professional Training: Operator training is available in factory.
- USA Technical Support: Dedicated support from qualified technicians and engineers based in the United States (optional).
CUTTING CAPACITY BY LASER POWER
Cutting thickness in millimeters (mm). Actual performance depends on material grade, assist gas, cutting parameters, and desired edge quality.
| Material | 1000W | 1500W | 2000W | 3000W |
|---|---|---|---|---|
| Carbon Steel | 0.4–12 | 0.4–16 | 0.4–18 | 0.4–20 |
| Stainless Steel | 0.4–5 | 0.4–6 | 0.4–8 | 0.4–12 |
| Brass | 0.4–3 | 0.4–5 | 0.4–6 | 0.4–8 |
| Aluminum | 0.4–3 | 0.4–6 | 0.4–8 | 0.4–10 |
TECHNICAL SPECIFICATIONS
| Feature | Specification |
|---|---|
| Working Area | 5 × 10 ft (Approx. 1500 × 3000 mm) |
| Optional Working Area | 5 × 20 ft |
| Maximum Laser Power | 3000W |
| Control System | CypCut E |
| Motion Controller | BoChu FSCUT2000E |
| Industrial Computer | Windows 11 |
| Laser Cutting Head | BoChu |
| X/Y Axis Motors | Leadshine 750W Servo Motors |
| Z Axis Motor | Leadshine 400W Servo Motor |
| Dimension Tolerance | 0.05 mm |
| Positioning Tolerance | 0.02 mm |
| Motion System | High-Quality Rack and Pinion Guide Rails |
| Gear Reducer | Italy MOTOVARIO |
| Cooling System | Hanli Water Chiller, 60Hz, 2kW |
| Transformer | 220V 3-Phase to 380V 3-Phase, 40kVA |
| Voltage Stabilizer | 380VAC, 50kVA |
| Assist Gas | Oxygen or Nitrogen |
| Gas Control | Nitrogen and Oxygen Proportional Valves |
| Machine Power Supply | 220V, 3-Phase |
| Power Consumption | 15–20 kW |
| Gross Weight | Approx. 3,000 lbs |
INCLUDED CONSUMABLES & ACCESSORIES
- 30 Cutting Nozzles
- 25 Protective Lenses
- 5 Ceramic Rings
- Transformer – 40kVA
- Voltage Stabilizer – 50kVA
- Hanli Water Chiller
- Oxygen and Nitrogen Proportional Valves
APPLICATIONS
- Industrial Sheet Metal Fabrication
- Carbon Steel and Stainless Steel Cutting
- Aluminum and Brass Fabrication
- Automotive and Machinery Components
- Metal Cabinets and Equipment Enclosures
- Custom Metal Parts Manufacturing
- Architectural and Decorative Metalwork
- Prototype and Production Cutting
WHY BUY FROM US?
Factory-Ready Equipment: High-quality components from recognized manufacturers, including BoChu, Leadshine, MOTOVARIO, and Hanli.
Delivered to Your Door: Import duties and freight included in the quoted machine price.
Tested Before Delivery: Machine setup, testing, and demonstration can be arranged before shipment or pickup.
USA-Based Technical Support: Our qualified technicians and engineers are available to assist with machine operation and technical questions.
Training & Installation Available: We can also provide operator training and installation services.
CONTACT US FOR A QUOTE
5 × 10 FT Model: Email us for pricing.
5 × 20 FT Model: $48,000
Call: 630-254-8655
Email us today for additional details, availability, and a formal quotation.
Warranty: One Year Parts
