Product Description

Used for 90W or big Machine, 3 pin connection

Please check with your current machine. if you have a 4 pin, you need to change the motor

Instructions of the Rotary Attachment

        Disconnect the Y-motor from the Y-driver.

1. Plug in the rotary attachments plug, into the Y-driver.
2. Put the rotary attachment on the work table.
3. Attach the object to the rotary attachment.
4. Modify the moving distance parameter of the Y-axis. The distance can be indicated to be πD/2. (D = the diameter of object)
5. Adjust the focus.
6. Start the engraving.
