CNC Router Milling KL-4040A Mold Maker Machine

Product in stock



Loading Updating cart...

CNC Router Milling KL-4040A Mold Maker Machine

Product Description


CNC Router Milling 4040A, all solid casting metal, best for computer control milling all kind of metal, plastic, wood, composite and many more. The structure is strong and solid to withstand all the hard forces. It is controlled by Mach3 or Mach4 using UC100 USB connection ( Computer Monitor is only for display, Not Included)

Click to apply Financing with leasestation.com

Tech support: 847-984-0882


Model KL-4040A, Table Moves
Working/ Traveling Area 400mm x  400mm x 200mm ( 15.75 x 17.75 x 7.87 inch)
Spindle Motor 2.2 KW  Water Cooling spindle
Motor Drive Closed Loop Stepper Motor/Driver
Drive Mechanism Precision Ballscrew
Resolution 0.01mm
Max Engraving Speed 10,000mm/min
Rotating Speed of Spindle 24,000rpm
Engraving Tools Up to 12.00mm
Frame Cast iron
Controlling Code Standard G code / M code
Operating Voltage 220V / Add a up transformer for 110VAC
Software Mach 3, or Mach4 CAD software, Not inlcudedDB 25 Connector
Machine size 1.1 x1.1 x1.65 m.

Propose: Metal molds, Aluminum, Bronze, Wood molds, Artificial Stone, Natural Stone, Plastic and so.

One Year Warranty
