NEMA23 381oz/in 3.5A Dual Shaft Stepper Motor KL23H2100-35-4B

Product in stock

This powerful 381oz/in NEMA23 stepper motor is well suited to medium sized motion control projects of all types.

Price

$39.99

Loading Updating cart...

NEMA23 381oz/in 3.5A Dual Shaft Stepper Motor KL23H2100-35-4B

Product Description

Specification:

NEMA 23 Frame

Shaft 1/4"

length: 20.6mm

381 oz In. Hybrid Motor

1.8° /200 Steps Per Rev.

3.5 Amps Current Per Phase

2.8 mH Inductance

4-wire  Bi-polar

Black to A+

Green to A-

Red to B+

Blue to B-

Downloads:

KL23H2100-35-4B Drawing (301 downloads)
